In scenarios such as logistics monitoring, vehicle management, and valuables tracking, GPS tags are the core tool for ensuring asset security. However, with the increase in technology abuse, it is common for GPS signals to be maliciously blocked. Criminals use metal shields, signal jammers, and even software attacks to make tags "lost" and then carry out theft, illegal transfer, and other behaviors. How to make GPS tags work stably in complex environments has become a pain point that users must solve. This article will provide a set of protection solutions that can be directly implemented from three dimensions: equipment selection, installation and deployment, and daily management.
Equipment selection: give priority to hardware with strong anti-interference ability
80% of the anti-shielding ability of GPS tags depends on their hardware configuration. When purchasing, you need to focus on the following core parameters to avoid signal interruption due to insufficient equipment performance.
Multi-band support
L1+L5 dual-band: Traditional GPS tags only support L1 band (1575.42MHz), which is easily covered by jammers in the same band; while L5 band (1176.45MHz) has higher signal power, stronger anti-interference ability, and uses more advanced modulation technology, which can effectively resist narrowband interference. For example, in the electromagnetic interference test, the positioning success rate of a certain brand of dual-frequency tags is 40% higher than that of single-frequency devices, and it performs more stably in complex environments such as urban canyons and tunnels.
Four-band expansion: Some high-end devices support L1/L2/L5/L6 four-bands, which can cover more satellite signals and further improve anti-interference redundancy.
Anti-interference chip integration
Dedicated anti-interference chip: Choose devices with built-in u-blox M8N, SiRFstarV and other anti-interference chips. This type of chip integrates limiting circuits, bandpass filters and low-noise amplifiers (LNA), which can automatically suppress out-of-band interference signals (such as mobile phones and Wi-Fi signals) and limit input power to prevent burning.
High input IP3 value: The input third-order intercept point (IP3) of the chip is a key indicator for measuring anti-interference ability. The higher the value (such as ≥-10dBm), the stronger the ability to suppress strong interference signals.
Multi-mode positioning and inertial navigation
GPS + Beidou + Wi-Fi + Bluetooth: When the GPS signal is completely blocked, the tag can automatically switch to Beidou satellites or scan the surrounding Wi-Fi/Bluetooth signals, and combine the location database to achieve seamless indoor and outdoor positioning (accuracy 2-10 meters). For example, after a logistics company used multi-mode tags, it could continue to report its location in GPS blind spots such as underground garages, and the cargo loss rate dropped by 70%.
Inertial navigation (IMU) backup: Devices with built-in accelerometers and gyroscopes can achieve short-term positioning (error ≤2%/minute) through inertial measurement when the GPS signal is lost, gaining critical time for tracking.
Installation and deployment: Scientific planning to reduce the risk of signal blocking
Even if the device has strong anti-interference ability, the wrong installation method will greatly reduce its performance. The deployment strategy needs to be optimized from three aspects: location selection, physical protection, and power supply guarantee.
Optimize the installation location
Avoid metal shielding: The metal shell will reflect the GPS signal, causing the receiving strength to drop by more than 30dB. When installing on a vehicle, give priority to the area below the front windshield (without metal mesh shielding) or the back of the rearview mirror, and avoid installing near the metal bracket of the dashboard; when installing on an asset, embed the tag into the non-metallic area inside the device (such as the interlayer of the plastic shell), or use 3M glue to fix it on the top of the asset (facing the sky).
Stay away from electromagnetic interference sources: Transformers, motors, inverters and other equipment will generate broadband noise interference. The installation point must be at least 1 meter away from such equipment, and the magnetic field strength must be tested with the mobile phone compass APP (if the value is >50μT, the position must be changed).
Physical protection design
Miniaturization and hiding: Choose a miniature tag with a size of ≤50mm×30mm×15mm, which can be hidden in hidden locations such as vehicle bumpers, container locks, and equipment gaps to reduce the probability of being discovered and shielded by criminals.
Anti-disassembly structure: Some tags adopt embedded design (such as embedded in the vehicle OBD interface or the internal circuit board of the device), or are equipped with photosensitive sensors and accelerometers. Once disassembled, they will immediately trigger an alarm and upload the last location. For example, a jeweler embedded the tag inside a necklace pendant, which is both beautiful and anti-disassembly, and the tracking success rate is 99%.
Power supply guarantee solution
Backup battery support: Choose a device with a built-in rechargeable lithium battery, which can still work for more than 72 hours after the main power is disconnected, to prevent criminals from making the tag invalid by cutting off the power.
Low power mode: Give priority to tags that support the "timed wake-up" function (such as reporting the location once every 30 minutes and sleeping for the rest of the time), with a standby current of ≤10μA, which can significantly extend the battery life and reduce signal interruptions caused by power exhaustion.
Daily management: Active monitoring and rapid response to shielding events
After the equipment is deployed, it is necessary to build an active defense system through signal monitoring, abnormal alarm, data backup and other means.
Real-time monitoring of signal strength
Management platform monitoring: Use the management platform provided by the supplier or a third-party APP (such as "GPS Toolbox") to view the signal-to-noise ratio (SNR) and carrier-to-noise ratio (C/N0) of the tag in real time. If the SNR drops from 40dB to below 20dB, or the C/N0 drops from 50dB-Hz to below 35dB-Hz, there may be interference, and the surrounding environment needs to be checked immediately.
Threshold alarm setting: Configure "trigger notification when SNR < 25dB" in the platform to detect signal abnormalities as soon as possible.
Abnormal behavior alarm mechanism
Station timeout alarm: If the device has not moved for 2 hours, it may have been blocked and hidden, and relevant personnel must be contacted immediately for verification;
Position jump alarm: If the distance between two adjacent positioning is greater than 5 kilometers (such as the vehicle "teleports" from the highway to the wilderness), it may encounter a signal deception attack, and other monitoring methods must be combined to confirm the safety of the asset.
Case: A fleet successfully intercepted 3 "blocking tags and stealing oil" incidents through abnormal behavior alarms, recovering losses of more than 200,000 yuan.
Data backup and recovery
Local storage: Choose a device with a TF card slot. During the shielding period, the data is temporarily stored locally and automatically uploaded after the signal is restored;
Cloud cache: Use a management platform that supports "offline cache" (such as Tencent Cloud and Alibaba Cloud). The tag can still store 7 days of data when there is no signal to ensure that the location trajectory during the shielding period can be traced.
Test verification: After installation, simulate shielding for 1 hour to confirm whether the data can be fully restored to avoid the loss of key information.
To prevent GPS tags from being shielded, a protection system must be built from the entire process of device selection, installation and deployment to daily management: select multi-band, anti-interference chips and multi-mode positioning devices to improve anti-interference capabilities from the hardware level; reduce signal blocking and interference risks through scientific installation; use active monitoring and rapid response mechanisms to intervene in time when shielding events occur.
