How Low-Power BLE Enables Pet Tracking

In today's society, pets are no longer simply animals; they have become integral members of many families. Their unconditional love and companionship bring endless warmth and joy to our lives. However, the issue of pet loss hangs like a sword of Damocles, constantly threatening this beautiful world.

According to relevant organizations, tens of millions of pets go missing worldwide each year, leaving many families with pain and anxiety. Traditional pet tracking methods, such as GPS trackers, while capable of locating pets, suffer from high power consumption and high costs. Against this backdrop, Bluetooth Low Energy (BLE) technology, with its advantages of low power consumption, low cost, and ease of integration, has gradually emerged in the pet tracking field, providing new safeguards for pet safety.

Basics and Advantages of Low-Power BLE Technology

Bluetooth Low Energy (BLE) is a type of Bluetooth technology designed for low-power, low-data-rate applications. Compared to traditional Bluetooth, BLE significantly reduces power consumption while maintaining a similar communication range, enabling devices to use smaller batteries and achieve longer battery life. This is crucial in pet tracking scenarios. Pet collars have limited space, making it difficult to accommodate large batteries. However, BLE's low power consumption allows compact tracking devices to operate for extended periods, reducing the need for frequent charging. Furthermore, BLE devices are relatively inexpensive, reducing the overall cost of pet tracking and making it more affordable for more pet owners.



Components of a BLE-Based Pet Tracking Device

A typical BLE-based pet tracking device consists of three main components: a BLE tag, a mobile application, and a cloud server. The BLE tag, typically mounted on a pet collar, contains a built-in BLE chip, antenna, and battery. It periodically transmits a signal containing its unique identification information. The mobile application, installed on the pet owner's phone, communicates with the BLE tag via Bluetooth, receives the tag's signal, and uploads information such as signal strength to a cloud server. The cloud server processes and analyzes the received data, calculating the distance and approximate location between the pet and owner, and then feeds the results back to the mobile application.



Several Common BLE Pet Tracking Implementation Modes

Close-Range Anti-Loss Mode

Principle: When the pet and owner are in close proximity, the BLE Signal Strength Indicator (RSSI) is used to estimate the distance between them. BLE tags periodically transmit signals, which the mobile app receives and measures. Generally speaking, a stronger signal indicates a closer distance, while a weaker signal indicates a greater distance. When the signal strength falls below a preset threshold, the app issues an alert, warning the owner that their pet may be moving away.

Use Scenario: Suitable for pets walking within relatively small areas, such as parks and residential areas. For example, an owner might be strolling in a park while their pet plays nearby. If the pet strays beyond a certain distance, the mobile app will issue an alert, preventing the pet from getting lost.

Geo-Fence Mode

How it works: A virtual safety zone, or geo-fence, is pre-set in the mobile app. When a pet enters or leaves this zone, the communication status between the BLE tag and the mobile app changes. The app monitors these changes, determines whether the pet has crossed the boundary, and promptly sends a notification to the owner.

Use Scenario: This is particularly useful for owners with a garden or who frequently take their pets to a specific location. For example, an owner might set up a geo-fence for their pet. If the pet attempts to escape, the phone will receive an alert, allowing the owner to take timely action to prevent the pet from getting lost or endangering the pet.

Historical Track Replay Mode

How it works: A BLE tag regularly records its location (by communicating with nearby BLE beacons with known locations or using the mobile device's positioning function) and stores this information locally or uploads it to a cloud server. A mobile application can retrieve this historical location data from the server and plot the pet's movement trajectory on a map.

Use scenario: If a pet becomes lost, the owner can review historical track playback to understand the pet's approximate range and path before disappearance, providing important clues for finding the pet. For example, if the owner discovers their pet is missing and can find the pet's last sighting on a street near their residential area by reviewing historical tracks, they can conduct a targeted search in that area.



Methods for Improving the Accuracy and Stability of BLE Pet Tracking

Optimizing Signal Processing Algorithms: Using advanced signal processing algorithms, such as the Kalman filter, to filter BLE signal strength, reduce the impact of signal fluctuations on distance estimation, and improve distance estimation accuracy.

Multi-beacon positioning technology: Multiple BLE beacons with known locations are deployed within the pet's activity area. By measuring the signal strength between the pet's BLE tag and multiple beacons, triangulation or multilateration algorithms are used to more accurately determine the pet's location.

Integrating other sensor data: BLE technology is combined with other sensors such as accelerometers and gyroscopes to measure the pet's movement status, assist in determining the pet's location and activity, and improve tracking stability and reliability.



Low-power BLE technology provides an efficient, economical, and practical solution for pet tracking. By effectively leveraging the characteristics and advantages of BLE technology and combining different tracking modes and methods, the accuracy and stability of pet tracking can be effectively improved, helping pet owners better protect their beloved pets.
